Major Features

• Support for the new multi-functional color display, RAXN-4000LCDGC, has been added. This main display/remote annunciator offers enhanced text readability and a user-friendly interface.
• Enhanced support has been added for the MIX-4020 and MIX-4021 photo-heat sensors, enabling low and high heat detection for FSAE operations. The updated configurator now recognizes a single address for the photo sensor and two sub-addresses for the heat sensors (Low and High). Region-specific low heat settings are also included, with support for NFPA (90°F) and FDNY (100°F) requirements.
• The system now supports the ability to individually correlate LED annunciators with specific input zones within the same node. Previously, LED annunciators mirrored each other’s statuses, limiting the number of input zones which could be individually monitored, on a single node.
• The configurator now supports exporting job files in CSV format, enabling users to efficiently perform mass edits to the tags column and re-import the file to apply the changes. Additionally, the job import process has been streamlined by allowing users to drag and drop .mdb or .csv files directly into the configurator, eliminating the need to use the “Import Job”.
• Users can now retrieve alarm and event logs directly from the panel using the new “Get Logs” option in the panel menu, eliminating the need for manual TeraTerm captures. Retrieved logs are automatically saved in the job builder folder in both the original and CSV formats, with timestamps included for easy reference and tracking.
• A new option is now available to prevent global node troubles from being propagated to other individual node groups within the fire alarm network, allowing for more isolated and accurate trouble reporting.

• Major Enhancements

Major improvements have been made to network operations for large sized network systems:
Faster system reset response.
Enhanced network activation performance for output devices.
Improved audio quality when digitized through the network, with clearer microphone sound.
Increased performance when broadcasting firmware to multiple nodes within the network.
Reduced job send time, improving overall system efficiency.

Minor Features

• New CO operation test feature for combo smoke-heat detectors. Added the ability to independently test CO functionality through the panel menu, bypassing time dependencies and magnet activation. Using the CO bypass command, users can directly activate the CO operation—streamlining testing procedures. Previously, testing required magnet activation, and a panel reset to create a 1-minute time window for CO detection.
• An optional checkbox has been added to allow users to pre-emptively disable all telephone lines when adding a new audio network controller module, providing greater control over system configuration.

Minor Enhancements

• Improvements made for job file validation when requiring audio.
• Increased number of devices which can be correlated to a walk test zone from 1000 to 10000.
• Improvements made to panel’s stability during manage job operations.
• Improved user experience by allowing users to make edits to inputs while in input/output summary tabs as well as allowing user to jump to respective inputs location within the job tree by using the “Jump to Definition”.
• Increased terms (any link is considered a term) limit from 32,000 to 65,000 per node.
• Enhanced logic equation handling to maintain correct switch references when a switch is deleted, preventing unintended ID shifts.
• General enhancements to firmware upgrade procedure.
• Added sensitivity range for MIX-4010-D within the configurator to match the manual
• Added the ability to write logic equations directly to the audio amplifiers.
• Improved reliability of copy node from existing job when creating a new job file.
• Added the ability to separate the LED activation status for evacuation and paging, so that when paging button is pressed, the evacuation LED will not illuminate or vice versa.
• Improved configurator user interface for resolution and scaling Windows Operating System.

As always, we appreciate your business and your understanding. If you have any questions or concerns, please contact the Application Group at [email protected].

Best Regards,
Mircom Group of Companies
